A WELL-ROUNDED ALTERNATIVE

Tavola™ Round Beams and Baffles offer a soft, rounded face profile that is pleasing to the eyes as well as the ears. Boasting a variety of color, finish, and perforation options that help enhance acoustics, these lightweight aluminum solutions are ideal for interior commercial spaces.

Our Standard Heavy Duty CertainTeed 15/16” EZ Stab Classic T-Grid Suspension System simplifies installations. Beams mount via hidden scissor clips, enabling single-beam access to the plenum.

Dimensions

  • Multitude of profile dimensions up to 12' long

Beam sizes

  • Diameter 1-9/16” (R: 25/32”)
  • Height: 2-1/2”, and 3” up to 12” in 1” increments

Key Features

  • Designed for easy plenum access
  • Perforation patterns provide elevated acoustics
  • Hidden scissor clips mount to standard heavy-duty 15/16" CertainTeed EZ Stab Classic T-grid suspension
  • Waste reduction with factory fabricated dimensional material
  • Downweight: reduce dead load with lightweight aluminum
  • Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
  • High recycled aluminum content
  • No VOCs: No added urea-formaldehyde
  • GREENGUARD Gold Certified
  • EPD and HPD available

Physical Data

  • Substrate: Aluminum
  • Warranty: 1 year Limited Warranty
  • Seismic rating: Zones A, B, C, D, E, F
  • Fire rating: Class A Fire Rated per ASTM E84
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • CAN/ULC-S102
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Weight: Varies 0.5 - 2.1 lbs/sq. ft.
  • Wind load: N/A
  • Recycled content: Up to 85%
  • Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
    • Cotton White: LR = 0.81



Dimensions

  • Multitude of profile dimensions up to 12' long

Beam sizes

  • Diameter 1-9/16” (R: 25/32”)
  • Height: 2-1/2”, and 3” up to 12” in 1” increments

Key Features

  • Designed for easy plenum access
  • Perforation patterns provide elevated acoustics
  • Hidden scissor clips mount to standard heavy-duty 15/16" CertainTeed EZ Stab Classic T-grid suspension
  • Waste reduction with factory fabricated dimensional material
  • Downweight: reduce dead load with lightweight aluminum
  • Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
  • High recycled aluminum content
  • No VOCs: No added urea-formaldehyde
  • GREENGUARD Gold Certified
  • EPD and HPD available

Physical Data

  • Substrate: Aluminum
  • Warranty: 1 year Limited Warranty
  • Seismic rating: Zones A, B, C, D, E, F
  • Fire rating: Class A Fire Rated per ASTM E84
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • CAN/ULC-S102
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Weight: Varies 0.5 - 2.1 lbs/sq. ft.
  • Wind load: N/A
  • Recycled content: Up to 85%
  • Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
    • Cotton White: LR = 0.81



CAD & PDF

Tavola Round

Name ID PDF DWG
Tavola Round Consolidated Tavola Round A1.0 – A1.10 PDF DWG

DOCUMENT LIBRARY

Document Library

Name Download
Tavola Round - Submittal Sheet PDF
Tavola Round - Data Sheet PDF
Tavola Round - 3-Part Spec DOCX
Terms & Conditions PDF
Limited Warranty PDF
Delivery, Storage and Handling N/A

Product Declarations

Name Download
EPD - Aluminum PDF
HPD - Beams and Baffles PDF
GREENGUARD Gold Certificate PDF

Sustainability Information

Overview
CertainTeed designs, engineers and manufactures ceiling systems that optimize interior environmental quality, material resources and energy usage by incorporating sustainable materials and employing sustainable practices in our manufacturing processes.  Solutions from CertainTeed may contribute to LEED BD+C and ID+C certification for schools, retail, hospitality, healthcare and commercial interiors.

Ecomedes
Our Ecomedes Sustainable Product Platform allows you to quickly access the product information and certifications you need, calculate contributions to LEED and other green building rating systems and create and save a group of products using the project feature. The information is free to access and always up to date. You can sign up for an account using your name and an email and start specifying!

Visit ECOMEDES
Ecomedes allows the AEC Community, Designers and Owners to find, compare and optimize the selection of sustainable building products for any project based on environmental characteristics such as certifications, ecolabels, and contributions to green building rating systems.

Indoor Environmental Quality
Meeting the rigorous and comprehensive standards for low emissions of VOC's, our GREENGUARD Gold Certified ceilings contribute to the overall indoor air quality and general health of a building space.

Product Declarations
From raw material extradition through final disposal or reuse, we can provide life-cycle assessments on many of our products environment and health impacts.
