Product Overview

Technical Specs

(More Info)

PIECE BY PIECE TO ACCESSIBLE DESIGN.

Designed using flat panels in a curved carrier, Torsion Spring Segmented metal ceilings offer point access and 100% access to the plenum from swing down panels making this sleek ceiling ideal for commercial spaces.

The key feature of this system is the engagement of the torsion spring mechanisms with the main and cross tees, allowing safe point access for sizes up to 36" x 120" and 48" x 48" in squares.

Product Details

Two panel size sets:

6" to 36" widths up to 120" long

48" width up to 48" long

Key Features

  • Swing-down feature allows point-access and 100% access to plenum
  • Square-edge design
  • Waste reduction with factory fabricated dimensional material
  • Downweight: reduce dead load with lightweight aluminum
  • Interior and exterior applications
  • Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
  • High recycled aluminum content
  • Class A Fire Rated, per ASTM E-84
  • No VOCs: No added urea-formaldehyde
  • GREENGUARD Gold Certified

Physical Data

  • Substrate: Aluminum
  • Warranty: 1 year Limited Warranty
  • Seismic rating: Zones A, B, C, D, E, F
  • Fire rating: Class A Fire Rated per ASTM E84
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
    • Film on metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Fire Rating: Class A Fire Rated per CAN/ULC-S102
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Weight: Varies 1.0 - 1.5 lbs/sq. ft.
  • Wind load: N/A
  • Recycled content: Up to 85%
  • Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
    • Cotton White: LR = 0.81



Two panel size sets:

6" to 36" widths up to 120" long

48" width up to 48" long

Key Features

  • Swing-down feature allows point-access and 100% access to plenum
  • Square-edge design
  • Waste reduction with factory fabricated dimensional material
  • Downweight: reduce dead load with lightweight aluminum
  • Interior and exterior applications
  • Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
  • High recycled aluminum content
  • Class A Fire Rated, per ASTM E-84
  • No VOCs: No added urea-formaldehyde
  • GREENGUARD Gold Certified

Physical Data

  • Substrate: Aluminum
  • Warranty: 1 year Limited Warranty
  • Seismic rating: Zones A, B, C, D, E, F
  • Fire rating: Class A Fire Rated per ASTM E84
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
    • Film on metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Fire Rating: Class A Fire Rated per CAN/ULC-S102
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Weight: Varies 1.0 - 1.5 lbs/sq. ft.
  • Wind load: N/A
  • Recycled content: Up to 85%
  • Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
    • Cotton White: LR = 0.81



ACOUSTICS

SOUND ABSORPTION (NRC) SUMMARY* Ceiling panels are available in a variety of perforation patterns for optimum acoustical performance. Sound absorption can be achieved by the addition of backing these panels with acoustical fabric or pad. *Acoustical Tests performed in accordance with ASTM C423 and ASTM E795, in a type E400 mounting. Test reports available upon request.

PERFORATION PATTERN % OPEN AREA ACOUSTICAL INFILL NRC
#103 20% Non-Woven Acoustic 0.80
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.90
#106 16% Non-Woven Acoustic 0.75
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.85
#115 12% Non-Woven Acoustic 0.65
Non-Woven Acoustic and 1.5" - 1.5 pcf Polywrapped Fiberglass 0.95
1.5" - 1.5 pcf Polywrapped Fiberglass 0.90
#119 8% Non-Woven Acoustic 0.70
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.75
#127 25% Non-Woven Acoustic 0.70
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.95
#132 20% Non-Woven Acoustic 0.75
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.90
#185 3.1% Non-woven 0.65
Non-woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.75
#188 6.3% Non-Woven 0.75
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.90
#201 19.6% Non-Woven Acoustic 0.75
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.75
