STYLISH LOOK. EASY ACCESS.

Our Torsion Spring metal ceilings deliver style and ease with its versatile carrier/grid system. Both flat and curved panels swing down ensuring safe access to the plenum making the system the ideal choice for casinos, airports and arenas.

The key feature of this system is the engagement of the torsion spring mechanisms with the main and cross tees, allowing safe point access for sizes up to 36" x 120" and 48" x 48" in squares.

Product Details

Two panel size sets:

6" to 36" widths up to 120" long

48" width up to 48" long



Key Features

  • Swing-down feature allows point-access and 100% access to plenum
  • Square-edge design
  • Waste reduction with factory fabricated dimensional material
  • Downweight: reduce dead load with lightweight aluminum
  • Interior and exterior applications
  • Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
  • High recycled aluminum content
  • No VOCs: No added urea-formaldehyde
  • GREENGUARD Gold Certified
  • EPD and HPD available

Physical Data

  • Substrate: Aluminum
  • Warranty: 1 year Limited Warranty
  • Seismic rating: Zones A, B, C, D, E, F
  • Fire rating: Class A Fire Rated per ASTM E84
    • Painted or anodized metal: Flame spread: < 25, Smoke < 50
    • Film on metal: Flame spread: < 25, Smoke < 50
  • Fire Rating: Class A Fire Rated per CAN/ULC-S102
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Weight: Varies 1.0 - 1.5 lbs/sq. ft.
  • Wind load: Per code (for exterior applications)
  • Recycled content: Up to 85%
  • Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
    • Cotton White: LR = 0.81

Two panel size sets:

6" to 36" widths up to 120" long

48" width up to 48" long



Key Features

  • Swing-down feature allows point-access and 100% access to plenum
  • Square-edge design
  • Waste reduction with factory fabricated dimensional material
  • Downweight: reduce dead load with lightweight aluminum
  • Interior and exterior applications
  • Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
  • High recycled aluminum content
  • No VOCs: No added urea-formaldehyde
  • GREENGUARD Gold Certified
  • EPD and HPD available

Physical Data

  • Substrate: Aluminum
  • Warranty: 1 year Limited Warranty
  • Seismic rating: Zones A, B, C, D, E, F
  • Fire rating: Class A Fire Rated per ASTM E84
    • Painted or anodized metal: Flame spread: < 25, Smoke < 50
    • Film on metal: Flame spread: < 25, Smoke < 50
  • Fire Rating: Class A Fire Rated per CAN/ULC-S102
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Weight: Varies 1.0 - 1.5 lbs/sq. ft.
  • Wind load: Per code (for exterior applications)
  • Recycled content: Up to 85%
  • Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
    • Cotton White: LR = 0.81

Get Inspired and Learn More

VISIT THE Ceilings and Walls, Specialty Ceilings and Walls LEARNING CENTER
VISIT THE Ceilings and Walls, Specialty Ceilings and Walls INSPIRATION GALLERY

[field_project_image]
Photos
Ohio Sports Arena
[field_project_image]
Photos
Williston Basin International Airport
[field_project_image]
Photos
Jordan-Hare Stadium (Auburn University)
[field_project_image]
Photos
Chicago Tribune Headquarters
[field_project_image]
Photos
Northwestern University Walter Athletics Center
[field_project_image]
Photos
The Empire Mall
[field_project_image]
Photos
Southwest General Hospital
[field_project_image]
Photos
Denver Union Station

CAD & PDF

Click on the + sign to view and download details and drawings for the product(s) listed below.

Torsion Spring - System Overview – Interior

Name ID PDF DWG
Torsion Spring TS-A1.0-A1.8 PDF DWG

EdgeLine Trim - Channel (Torsion Spring)

Name ID PDF DWG
Edgeline Profiles Edgeline-A1.0 PDF DWG
Edgeline EX1 Clip Edgeline-A1.1 PDF DWG
Edgeline Corners-Splices Edgeline-A1.2 PDF DWG
Edgeline Horizontal Curves Edgeline-A1.3 PDF DWG
Edgeline Torsion Spring Edgeline-A1.4 PDF DWG

ACOUSTICS

SOUND ABSORPTION (NRC) SUMMARY* Ceiling panels are available in a variety of perforation patterns for optimum acoustical performance. Sound absorption can be achieved by the addition of backing these panels with acoustical fabric or pad. *Acoustical Tests performed in accordance with ASTM C423 and ASTM E795, in a type E400 mounting. Test reports available upon request.

PERF PATTERN % OPEN AREA ACOUSTICAL INFILL NRC
#103 20% Non-Woven Acoustic 0.80
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.90
#106 16% Non-Woven Acoustic 0.75
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.85
#115 12% Non-Woven Acoustic 0.65
Non-Woven Acoustic and 1.5" - 1.5 pcf Polywrapped Fiberglass 0.95
1.5" - 1.5 pcf Polywrapped Fiberglass 0.90
#119 8% Non-Woven Acoustic 0.70
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.75
#127 25% Non-Woven Acoustic 0.70
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.95
#132 20% Non-Woven Acoustic 0.75
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.90
#185 3.1% Non-woven 0.65
Non-woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.75
#188 6.3% Nonwoven 0.75
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.90
#201 19.6% Non-Woven Acoustic 0.75
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.75

DOCUMENT LIBRARY

Document Library

Name Download
Torsion Spring - Data Sheet PDF
Torsion Spring - Technical Specifications DOCX
Torsion Spring - Submittal Sheet PDF
Limited Warranty PDF
Terms & Conditions PDF
Cleaning Instructions PDF
Delivery, Storage and Handling N/A
Torsion Spring - Data Sheet - Canada PDF
Torsion Spring - Submittal Sheet - Canada (French) PDF
Torsion Spring - Submittal Sheet - Canada PDF

Product Declarations

Name Download
EPD - Aluminum PDF
EPD - Steel PDF
HPD - CertainTeed Plank and Tile PDF
GREENGUARD Gold Certificate PDF

Sustainability Information

Overview

CertainTeed designs, engineers and manufactures ceiling systems that optimize interior environmental quality, material resources and energy usage by incorporating sustainable materials and employing sustainable practices in our manufacturing processes. Solutions from CertainTeed may contribute to LEED BD+C and ID+C certification for schools, retail, hospitality, healthcare and commercial interiors.

Ecomedes

Our Ecomedes Sustainable Product Platform allows you to quickly access the product information and certifications you need, calculate contributions to LEED and other green building rating systems and create and save a group of products using the project feature. The information is free to access and always up to date. You can sign up for an account using your name and an email and start specifying!

Visit ECOMEDES

Ecomedes allows the AEC Community, Designers and Owners to find, compare and optimize the selection of sustainable building products for any project based on environmental characteristics such as certifications, ecolabels, and contributions to green building rating systems.

Indoor Environmental Quality

Meeting the rigorous and comprehensive standards for low emissions of VOC's, our GREENGUARD Gold Certified ceilings contribute to the overall indoor air quality and general health of a building space.

Product Declarations

From raw material extradition through final disposal or reuse, we can provide life-cycle assessments on many of our products environment and health impacts.

EPD - Aluminum

EPD - Steel

HPD - CertainTeed Plank and Tile
