High Profile Series™ - Horizontally Curved Baffles

Product Overview

Technical Specs

(More Info)

Warranty

(More Info)

CEILINGS THAT MAKE WAVES.

Modern curves and engaging textures. High Profile Series™ Horizontally Curved Baffle ceiling system use extruded aluminum profiles to create playful, contemporary ceilings with seamless baffled design.

Our Unistrut® support system and custom fabrication capabilities let ceiling designs feature intriguing combinations of curve arcs and radii, as well as baffle heights and profiles.

Product Details

Beam Sizes:

  • Aero Profile
    • 1-5/8" x 6-3/8"
  • Beam Profile
    • 1-1/2" x 4-3/8"
    • 1-1/2" x 6-3/8"
    • 1-1/2" x 8-3/8"
    • 2" x 8"
    • 4" x 4"
  • Beam - Open
    • 4" x 4"

Note: Client specific shapes and finishes available

Key Features

  • Extruded aluminum profiles with exacting fit and finish
  • Seamless baffles up to 20 feet in length
  • Minimum radius 48" (except where otherwise specified)
  • Arc lengths 4 feet to 20 feet
  • Unistrut® support system
  • Client-specific suspension systems
  • Patented locking mechanism
  • Recycled content
  • No VOCs: No added urea-formaldehyde
  • GREENGUARD Gold Certified
  • EPD and HPD available

Physical Data

  • Substrate: Aluminum
  • Warranty: 1 year Limited Warranty
  • Seismic rating: Zones A, B, C, D, E, F
  • Fire rating: Class A Fire Rated per ASTM E84
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Fire Rating: Class A Fire Rated per CAN/ULC-S102
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Weight: Varies 2.0 - 4.0 lbs/sq. ft.
  • Wind load: N/A
  • Recycled content: Minimum of 50%
  • Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
    • Cotton White: LR = 0.81

Beam Sizes:

  • Aero Profile
    • 1-5/8" x 6-3/8"
  • Beam Profile
    • 1-1/2" x 4-3/8"
    • 1-1/2" x 6-3/8"
    • 1-1/2" x 8-3/8"
    • 2" x 8"
    • 4" x 4"
  • Beam - Open
    • 4" x 4"

Note: Client specific shapes and finishes available

Key Features

  • Extruded aluminum profiles with exacting fit and finish
  • Seamless baffles up to 20 feet in length
  • Minimum radius 48" (except where otherwise specified)
  • Arc lengths 4 feet to 20 feet
  • Unistrut® support system
  • Client-specific suspension systems
  • Patented locking mechanism
  • Recycled content
  • No VOCs: No added urea-formaldehyde
  • GREENGUARD Gold Certified
  • EPD and HPD available

Physical Data

  • Substrate: Aluminum
  • Warranty: 1 year Limited Warranty
  • Seismic rating: Zones A, B, C, D, E, F
  • Fire rating: Class A Fire Rated per ASTM E84
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Fire Rating: Class A Fire Rated per CAN/ULC-S102
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Weight: Varies 2.0 - 4.0 lbs/sq. ft.
  • Wind load: N/A
  • Recycled content: Minimum of 50%
  • Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
    • Cotton White: LR = 0.81
