A CLASSIC LOOK WITH THE DURABILITY TO MATCH.

We optimized our Hook-On ceiling panels for those who need the most adaptable and customizable metal ceiling available. The system allows architects to create nearly any design while maintaining panel performance, an ideal solution for a variety of commercial and industrial applications.

The key feature of this system is the variable carrier system and custom perforation options. The benefit is design flexibility without sacrificing proficiency or accessibility.

Product Details

Two panel size sets:

6" to 24" widths up to 120" long

30" width up to 60" long

Key Features

  • Square-edge design
  • Waste reduction with factory fabricated dimensional material
  • Downweight: reduce dead load with lightweight aluminum
  • Easy plenum access
  • Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
  • High recycled aluminum content
  • No VOCs: No added urea-formaldehyde
  • GREENGUARD Gold Certified
  • Wide variety of custom, patent-pending perforation designs and sizes available for 2’ x 2’ or 2’ x 4’ panels



Physical Data

  • Substrate: Aluminum
  • Warranty: 1 year
  • Seismic rating: Zones A, B, C, D, E, F
  • Fire rating: Class A Fire Rated per ASTM E84
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Weight: Varies 1.0 - 1.5 lbs/sq. ft.
  • Wind load: Per code (for exterior applications)
  • Recycled content: Up to 85%
  • Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
    • Cotton White: LR = 0.81

Two panel size sets:

6" to 24" widths up to 120" long

30" width up to 60" long

Key Features

  • Square-edge design
  • Waste reduction with factory fabricated dimensional material
  • Downweight: reduce dead load with lightweight aluminum
  • Easy plenum access
  • Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
  • High recycled aluminum content
  • No VOCs: No added urea-formaldehyde
  • GREENGUARD Gold Certified
  • Wide variety of custom, patent-pending perforation designs and sizes available for 2’ x 2’ or 2’ x 4’ panels



Physical Data

  • Substrate: Aluminum
  • Warranty: 1 year
  • Seismic rating: Zones A, B, C, D, E, F
  • Fire rating: Class A Fire Rated per ASTM E84
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Weight: Varies 1.0 - 1.5 lbs/sq. ft.
  • Wind load: Per code (for exterior applications)
  • Recycled content: Up to 85%
  • Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
    • Cotton White: LR = 0.81

Get Inspired and Learn More

REVIT, CAD & PDF

Click on the + sign to view and download details and drawings for the product(s) listed below.

Hook-On – System Overview

Name ID PDF DWG
Hook-On Consolidated - Interior HOOK-ON-A1.0-A1.10 PDF DWG

EdgeLine Trim - Channel (Torsion Spring)

Name ID PDF DWG
Edgeline Profiles Edge-A1.0 PDF DWG
Edgeline EX1 Clip Edge-A1.6 PDF DWG
Edgeline Corners-Splices Edge-A1.7 PDF DWG
Edgeline Horizontal Curves Edge-A1.8 PDF DWG

ACOUSTICS

SOUND ABSORPTION (NRC) SUMMARY* Ceiling panels are available in a variety of perforation patterns for optimum acoustical performance. Sound absorption can be achieved by the addition of backing these panels with acoustical fabric or pad. *Acoustical Tests performed in accordance with ASTM C423 and ASTM E795, in a type E400 mounting. Test reports available upon request.

PERFORATION PATTERN % OPEN AREA ACOUSTICAL INFILL NRC
#103 20% Non-Woven Acoustic 0.80
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.90
#106 16% Non-Woven Acoustic 0.75
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.85
#115 12% Non-Woven Acoustic 0.65
Non-Woven Acoustic and 1.5" - 1.5 pcf Polywrapped Fiberglass 0.95
1.5" - 1.5 pcf Polywrapped Fiberglass 0.90
#119 8% Non-Woven Acoustic 0.70
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.75
#127 25% Non-Woven Acoustic 0.70
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.95
#132 20% Non-Woven Acoustic 0.75
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.90
#185 3.1% Non-woven 0.65
Non-woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.75
#188 6.3% Nonwoven 0.75
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.90
#201 19.6% Non-Woven Acoustic 0.75
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.75

DOCUMENT LIBRARY

Document Library

Name Download
Product Guide - Hook On
Hunter Douglas Ceilings & Walls Product Guide
Hook-On - Submittal Sheet
Hook-On - Technical Specifications
Terms & Conditions
Limited Warranty
Cleaning Instructions
GREENGUARD Gold Certificate
Sell Sheet – Custom Perforations

Product Declarations

Name Download
EPD - Aluminum
EPD - Steel

Sustainability Information



Overview
Hunter Douglas Ceilings & Walls from CertainTeed designs, engineers and manufactures ceiling systems that optimize interior environmental quality, material resources
 and energy usage by incorporating sustainable materials and employing sustainable practices in our manufacturing processes.  Solutions from CertainTeed may contribute to LEED BD+C and ID+C certification for schools, retail, hospitality, healthcare and commercial interiors.

SmartBIM ecoScorecard
Our ecoScorecard LEED calculator helps customers search and evaluate the impact of ceilings products against leading environmental rating systems. Using the most up-to-date data in the marketplace, ecoScorecard provides clear, concise product information as well as supporting documentation.

Indoor Environmental Quality
Meeting the rigorous and comprehensive standards for low emissions of VOC's
, our
GREENGUARD Gold Certified ceilings contribute to the overall indoor air quality and general health of a building space.

Product Declarations
From raw material extradition through final disposal or reuse, we can provide life-cycle assessments on many of our products environment and health impacts.

EPD - Aluminum

EPD - Steel
