Product Overview

MIX. MATCH. WOW.

Our Combi-Line brings together linear metal and felt products for ceilings with complete creative flexibility and practical performance.

Customize metal panels in any color or wood finish and combine them with the rich textural warmth of our linear felt panels to create depth, dimension, and variegated tonal palettes across the ceiling plane. Combi-Line features a modular system with square and round panel profiles, four standard carrier modules, and scalable acoustical performance.

Dimensions

  • Standard Dimensions: 8' panel lengths
    • HeartFelt Linear:
      • 40HL55   – 40mm x 55mm,   1-9/16" x 2-3/16"
      • 40HL80  – 40mm x 80mm,  1-9/16" x 3-1/8"
      • 40HL105 – 40mm x 105mm, 1-9/16" x 4-1/8"
    • HeartFelt Round:
      • 40HR64  – 40mm x 64mm,  1-9/16" x 2-1/2"
    • Tavola Linear (metal):
      • 40TL55   – 40mm x 55mm,   1-9/16" x 2-3/16"
      • 40TL80   – 40mm x 80mm,  1-9/16" x 3-1/8"
      • 40TL105 – 40mm x 105mm, 1-9/16" x 4-1/8"

Key Features

  • Modular system with both square and round profile design offers easy plenum access
  • Available with four standard carrier modules.
  • Standard and custom perforations available for Tavola panels to elevate acoustics
  • Compatible with industry standard lighting, HVAC, fire safety and security components

Physical Data

  • MATERIAL:
    • Tavola Panels: Aluminum;
    • HeartFelt®: Non-Woven PES fibers (felt)
  • FIRE RATING
    • Class A Fire Rated per ASTM E84 and ASTM and ASTM E1264 (Heartfelt)
    • Canada - per CAN/ULC S102.2-10
  • SEISMIC RATING: ZONES A,B,C,D,E,F
  • VISUAL CONSIDERATIONS
    • Given the unique and special nature of our HeartFelt®  ceiling product, steps should be taken (before and during installation, as well as over the lifetime of the ceiling) to avoid or minimize static and the accumulation of dust, lint, dirt or airborne particles on or around the felt. Manufacturer does not warrant against or take responsibility for any such static or accumulation.
  • RECYCLED CONTENT: Metal – up to 85%
  • LIGHT REFLECTANCE: Varies with color
  • WARRANTY
    • 1-year Limited Warranty.
    • Full warranty information can be found at certainteed.com/warranty

Dimensions

  • Standard Dimensions: 8' panel lengths
    • HeartFelt Linear:
      • 40HL55   – 40mm x 55mm,   1-9/16" x 2-3/16"
      • 40HL80  – 40mm x 80mm,  1-9/16" x 3-1/8"
      • 40HL105 – 40mm x 105mm, 1-9/16" x 4-1/8"
    • HeartFelt Round:
      • 40HR64  – 40mm x 64mm,  1-9/16" x 2-1/2"
    • Tavola Linear (metal):
      • 40TL55   – 40mm x 55mm,   1-9/16" x 2-3/16"
      • 40TL80   – 40mm x 80mm,  1-9/16" x 3-1/8"
      • 40TL105 – 40mm x 105mm, 1-9/16" x 4-1/8"

Key Features

  • Modular system with both square and round profile design offers easy plenum access
  • Available with four standard carrier modules.
  • Standard and custom perforations available for Tavola panels to elevate acoustics
  • Compatible with industry standard lighting, HVAC, fire safety and security components

Physical Data

  • MATERIAL:
    • Tavola Panels: Aluminum;
    • HeartFelt®: Non-Woven PES fibers (felt)
  • FIRE RATING
    • Class A Fire Rated per ASTM E84 and ASTM and ASTM E1264 (Heartfelt)
    • Canada - per CAN/ULC S102.2-10
  • SEISMIC RATING: ZONES A,B,C,D,E,F
  • VISUAL CONSIDERATIONS
    • Given the unique and special nature of our HeartFelt®  ceiling product, steps should be taken (before and during installation, as well as over the lifetime of the ceiling) to avoid or minimize static and the accumulation of dust, lint, dirt or airborne particles on or around the felt. Manufacturer does not warrant against or take responsibility for any such static or accumulation.
  • RECYCLED CONTENT: Metal – up to 85%
  • LIGHT REFLECTANCE: Varies with color
  • WARRANTY
    • 1-year Limited Warranty.
    • Full warranty information can be found at certainteed.com/warranty
