ENDLESS DESIGN. LASTING IMPRESSION.

Long, uninterrupted panel lengths make our 300C ceiling system a good choice to make a big impression. With a variety of lengths and widths and a concealed suspension system, 300C panels create a clean appearance in interior and exterior applications.

This ceiling system is designed to withstand wind loads in exterior environments. The benefit is the ceiling can create a continuous design from interior to exterior.

Product Details

Panel sizes:



Panel width: 12" nom. [300 mm]



Panel length: 3' to 19'-8"

Key Features

  • Bevel-edge design
  • Waste reduction with factory fabricated dimensional material
  • Downweight: reduce dead load with lightweight aluminum
  • Interior and exterior applications
  • Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
  • Perforated panels available for ventilation
  • Factory assembled access doors available
  • Miami-Dade NOA 21-0308.02, (expires May 5, 2026)
  • Ventilation panels available; see Miami-Dade certificate.
  • High recycled aluminum content
  • No VOCs: No added urea-formaldehyde
  • GREENGUARD Gold Certified
  • EPD and HPD available

Physical Data

  • Substrate: Aluminum
  • Warranty: 1-year Limited Warranty
  • Seismic rating: Zones A, B, C, D, E, F
  • Fire rating: Class A Fire Rated per ASTM E84
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Fire Rating: Class A Fire Rated per CAN/ULC-S102
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Weight: Varies 0.5 - 0.75 lbs/sq. ft.
  • Wind load: Per code
    • Designed and tested in accordance with the requirements of the Florida Building Code 7th edition (2020), including the High Velocity Hurricane Zone (HVHZ) provisions and Miami-Dade requirements.
    • Miami-Dade NOA 21-0308.02, (expires May 5, 2026)
  • Recycled content: Up to 92%
  • Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
    • Cotton White: LR = 0.81

Panel sizes:



Panel width: 12" nom. [300 mm]



Panel length: 3' to 19'-8"

Key Features

  • Bevel-edge design
  • Waste reduction with factory fabricated dimensional material
  • Downweight: reduce dead load with lightweight aluminum
  • Interior and exterior applications
  • Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
  • Perforated panels available for ventilation
  • Factory assembled access doors available
  • Miami-Dade NOA 21-0308.02, (expires May 5, 2026)
  • Ventilation panels available; see Miami-Dade certificate.
  • High recycled aluminum content
  • No VOCs: No added urea-formaldehyde
  • GREENGUARD Gold Certified
  • EPD and HPD available

Physical Data

  • Substrate: Aluminum
  • Warranty: 1-year Limited Warranty
  • Seismic rating: Zones A, B, C, D, E, F
  • Fire rating: Class A Fire Rated per ASTM E84
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Fire Rating: Class A Fire Rated per CAN/ULC-S102
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Weight: Varies 0.5 - 0.75 lbs/sq. ft.
  • Wind load: Per code
    • Designed and tested in accordance with the requirements of the Florida Building Code 7th edition (2020), including the High Velocity Hurricane Zone (HVHZ) provisions and Miami-Dade requirements.
    • Miami-Dade NOA 21-0308.02, (expires May 5, 2026)
  • Recycled content: Up to 92%
  • Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
    • Cotton White: LR = 0.81
