WinterGuard® waterproofing shingle underlayment is the solution for winning the battle against water penetration in your roof's most vulnerable places. WinterGuard is a composite material of asphalt polymers, formed into a rolled sheet. The asphalt makes it vapor-tight, and the polymers make the asphalt elastic and sticky. This protective barrier is able to stretch and seal around nails driven through it.
WinterGuard is one of the key components in the CertainTeed Integrity Roof System® which is comprised of underlayments, shingles, accessory products and ventilation all working together. The Integrity Roof System is designed to provide optimum performance--no matter the weather conditions.
- Granular – Embedded granules for superior traction during application
- Sand – Embedded sand to enhance traction during application
- Metal – high temperature textured surface underlayment, great for use under metal, shingle, slate or mechanically-fastened tile roofs.
- HT – high temperature enhanced skid resistant top film surface, great for use under shingle, metal, slate and tile roofs.
Product Overview
Technical Specs
Installation
Warranty
Get Inspired and Learn More
Technical Information
Choose your option - WinterGuard comes in four different surface finishes: Sand, Granular, Metal and Film. Consider the design and slope of the roof, combined with your personal preference..
SAND
- Embedded sand to enhance traction during application
- Improved exposure prior to shingling over
- Very effective under tile
- Meets ASTM D1970
- Length: 65 ft. (short roll 32.5 ft.)
- Width: 3 ft.
- 68 lbs. per roll (short roll 35.5 lbs. per roll)
GRANULAR
- Embedded granules for superior traction during application
- Improved exposure prior to shingling over
- Very effective under tile
- Meets ASTM D1970
- Length: 65 ft.
- Width: 3 ft.
- 68 lbs. per roll
METAL
- Top Surface: Tear Resistant Film
- Back Surface: Silicone-coated Release Film
- Meets ASTM D1970
- Dimensions: 39-3/8" x 61' (200 sq. ft.)
- Thickness: 60 mils
- 60 lbs. per roll
HIGH TACK / HIGH TEMPERATURE
- Enhanced skid-resistant top film surface
- An advanced waterproofing underlayment for shingle, metal, slate and tile roofs
- Specially formulated to resist high roof temperatures under metal roofs
- Meets ASTM D1970
- Length: 65 ft.
- Width: 3 ft.
- 50 lbs. per roll
Miami-Dade Product Control Acceptance: Please see the Notice of Acceptance (NOA) to determine approved products by manufacturing location.
Installation
Easy Installation WinterGuard's adhesive bottom surface is protected with a disposable silicone coated release film, which is split down the middle for simple and cost-effective application. The "Peal & Flop" method is especially effective in valleys and other difficult places using manageable lengths. Even more important, WinterGuard can be repositioned before deck adhesion occurs. For additional installation instructions, refer to the Underlayment Installation Instructions.
Installation
Warranty Details
WinterGuard is warranted against manufacturing defects and to remain watertight for the same period as the warranty duration carried by the shingles applied above it -- up to a maximum of 50 years.
Warranty
Export Information
WinterGuard® asphalt roofing shingles are available for Export. Please review the related brochures for additional information.
