CLASSIC DESIGN. INFINITE POSSIBILITIES.

Simple and cost-effective commercial metal ceiling systems. Lay-In metal ceilings offer classic ceiling solutions, featuring recycled content, numerous sizes and edge options, and compatibility with standard features. Simple and economical way to add metal ceilings to a project.

The key feature of this system is the ease of installation. The benefit is no tools or fasteners required and easy access to plenum space.

PRODUCT DETAILS

Two panel size sets:

6", 12", 18", 20", 24" widths up to 96" long

30" width up to 60" long

Key Features

  • Edge options: square, flush, reveal
  • Curved Lay-in available
  • Waste reduction with factory fabricated dimensional material
  • Downweight: reduce dead load with lightweight aluminum
  • Easy installation – no fasteners/tools required
  • Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
  • High recycled aluminum content
  • No VOCs: No added urea-formaldehyde
  • GREENGUARD Gold Certified
  • EPD and HPD available

Physical Data

  • Substrate: Aluminum
  • Warranty: 1 year Limited Warranty
  • Seismic rating: Zones A, B, C, D, E, F
  • Fire rating: Class A Fire Rated per ASTM E84
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Fire Rating: Class A Fire Rated per CAN/ULC-S102
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Weight: Varies 0.75 - 1.0 lbs/sq. ft.
  • Wind load: N/A
  • Recycled content: Up to 85%
  • Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
    • Cotton White: LR = 0.81

Two panel size sets:

6", 12", 18", 20", 24" widths up to 96" long

30" width up to 60" long

Key Features

  • Edge options: square, flush, reveal
  • Curved Lay-in available
  • Waste reduction with factory fabricated dimensional material
  • Downweight: reduce dead load with lightweight aluminum
  • Easy installation – no fasteners/tools required
  • Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
  • High recycled aluminum content
  • No VOCs: No added urea-formaldehyde
  • GREENGUARD Gold Certified
  • EPD and HPD available

Physical Data

  • Substrate: Aluminum
  • Warranty: 1 year Limited Warranty
  • Seismic rating: Zones A, B, C, D, E, F
  • Fire rating: Class A Fire Rated per ASTM E84
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Fire Rating: Class A Fire Rated per CAN/ULC-S102
    • Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
  • Weight: Varies 0.75 - 1.0 lbs/sq. ft.
  • Wind load: N/A
  • Recycled content: Up to 85%
  • Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
    • Cotton White: LR = 0.81

CAD & PDF

Click on the + sign to view and download details and drawings for the product(s) listed below.

Lay-In - System Overview – Interior

Name ID PDF DWG
Lay-In Consolidated - Interior LAYIN-A1.0-A1.9 PDF DWG

EdgeLine Trim - Channel (Lay-In)

Name ID PDF DWG
Edgeline Profiles Edgeline-A1.0 PDF DWG
Edgeline EX1 Clip Edgeline-A1.1 PDF DWG
Edgeline Corners-Splices Edgeline-A1.2 PDF DWG
Edgeline Horizontal Curves Edgeline-A1.3 PDF DWG
Edgeline Lay-In Edgeline-A1.5 PDF DWG

ACOUSTICS

SOUND ABSORPTION (NRC) SUMMARY* Ceiling panels are available in a variety of perforation patterns for optimum acoustical performance. Sound absorption can be achieved by the addition of backing these panels with acoustical fabric or pad. *Acoustical Tests performed in accordance with ASTM C423 and ASTM E795, in a type E400 mounting. Test reports available upon request.

PERFORATION PATTERN % OPEN AREA ACOUSTICAL INFILL NRC
#103 20% Non-Woven Acoustic 0.80
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.90
#106 16% Non-Woven Acoustic 0.75
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.85
#115 12% Non-Woven Acoustic 0.65
Non-Woven Acoustic and 1.5" - 1.5 pcf Polywrapped Fiberglass 0.95
1.5" - 1.5 pcf Polywrapped Fiberglass 0.90
#119 8% Non-Woven Acoustic 0.70
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.75
#127 25% Non-Woven Acoustic 0.70
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.95
#132 20% Non-Woven Acoustic 0.75
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.90
#185 3.1% Non-woven 0.65
Non-woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.75
#188 6.3% Nonwoven 0.75
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.90
#201 19.6% Non-Woven Acoustic 0.75
Non-Woven Acoustic and 1" - 1.5 pcf Polywrapped Fiberglass 0.75

DOCUMENT LIBRARY

Document Library

Name Download
Lay-In - Submittal Sheet PDF
Lay-In - Data Sheet PDF
Technical Specifications DOCX
Terms & Conditions PDF
Limited Warranty PDF
Cleaning Instructions PDF
Lay-In - Submittal Sheet - Canada PDF
Lay-In - Data Sheet - Canada PDF
Lay-In - Data Sheet - Canada (French) PDF
Lay-In - Submittal Sheet - Canada (French) PDF

Product Declarations

Name Download
EPD - Aluminum PDF
EPD - Steel PDF
HPD - CertainTeed Plank and Tile PDF
GREENGUARD Gold Certificate PDF

Sustainability Information

Overview
CertainTeed designs, engineers and manufactures ceiling systems that optimize interior environmental quality, material resources and energy usage by incorporating sustainable materials and employing sustainable practices in our manufacturing processes.  Solutions from CertainTeed may contribute to LEED BD+C and ID+C certification for schools, retail, hospitality, healthcare and commercial interiors.

Ecomedes
Our Ecomedes Sustainable Product Platform allows you to quickly access the product information and certifications you need, calculate contributions to LEED and other green building rating systems and create and save a group of products using the project feature. The information is free to access and always up to date. You can sign up for an account using your name and an email and start specifying!

Visit ECOMEDES
Ecomedes allows the AEC Community, Designers and Owners to find, compare and optimize the selection of sustainable building products for any project based on environmental characteristics such as certifications, ecolabels, and contributions to green building rating systems.

Indoor Environmental Quality
Meeting the rigorous and comprehensive standards for low emissions of VOC's, our GREENGUARD Gold Certified ceilings contribute to the overall indoor air quality and general health of a building space.

Product Declarations
From raw material extradition through final disposal or reuse, we can provide life-cycle assessments on many of our products environment and health impacts.

EPD - Aluminum

EPD - Steel

HPD - CertainTeed Plank and Tile



Sustainability Docs
